PAPER ROLLS
Installing the Paper Roll into your AX-100
Your cash register comes fitted with a thermal printer which uses a 58mm paper
roll. If a customer receipt is not always required, then there is a paper saving
option available by pressing the button on the keyboard (this is indicated
by an LED on the display). A receipt is available on request after the sale by
depressing the button.
Fig 1
Before installing the paper roll, be sure to do the following:
Orient the paper roll so that it rotates in a counter clockwise direction, as shown in
above.
Note
1. As thermal paper is used, it has a right and wrong side for printing. If you
install it the wrong way round (the heat sensitive side away from the print
head) no printing will be possible.
2. Carefully avoid touching the metal paper cutter when removing the paper
cover, it is very sharp.
