GEM 1235 User Manual

6 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Note: A valve specific mounting kit is required for assembly. For designing the mounting kit, the valve type, nominal size, control
function and actuator size must be stated.
Order codes
1 Type Code
Electrical position indicator 1235
2 Fieldbus Code
Without 000
3 Accessory Code
Accessory Z
4 Device version Code
Open/Closed position feedback,
programming input,
high visibility optical position indicator,
IO-Link communication
3E
Open/Closed position feedback,
high visibility optical position indicator
3S
Open/Closed position feedback inversed,
programming input,
high visibility optical position indicator,
IO-Link communication
4E
4 Device version Code
Open/Closed position feedback inversed,
high visibility optical position indicator
4S
5 Electrical connection Code
M12 plug, 5-pin M125
6 Travel sensor version Code
Potentiometer, 30 mm length 030
Potentiometer, 50 mm length 050
Potentiometer, 75 mm length 075
7 Housing material Code
PVDF base, black, PPR natural cover,
M16 thread PEEK
G10
8 Special version Code
UL approval U
Order example
Ordering option Code Description
1 Type 1235 Electrical position indicator
2 Fieldbus 000 Without
3 Accessory Z Accessory
4 Device version 3E Open/Closed position feedback,
programming input,
high visibility optical position indicator,
IO-Link communication
5 Electrical connection M125 M12 plug, 5-pin
6 Travel sensor version 030 Potentiometer, 30 mm length
7 Housing material G10 PVDF base, black, PPR natural cover,
M16 thread PEEK
8 Special version U UL approval
