7 Technical data
7.1 Medium
Working medium: Compressed air and inert gases
Dust content: Class 3, max. particle size 5 μm, max. particle density 5 mg/m³
Pressure dew point: Class 3, max. pressure dew point -20 °C
Oil content: Class 3, max. oil concentration 1 mg/m³
Quality classes to DIN ISO 8573-1
7.2 Temperature
Storage temperature: -10 — 60 °C
7.3 Pressure
Operating pressure: 0 to 10 bar (max. 40 °C)
0 to 8 bar (max. 60 °C)
The applied pressure must not exceed the maximum control pressure of the process valve.
Flow rate: 15 Nl/min
Air consumption: 0 Nl/min (when idle)
7.4 Product compliance
EMC Directive: 2014/30/EU
Technical standards used:
Interference emission: DIN EN 61000-6-4 (Sep. 2011)
Interference emission class: Class A
Interference emission group: Group 1
Interference resistance: DIN EN 61000-6-2 (March 2006)
7.5 Mechanical data
Installation position: Optional
Protection class: IP 65 acc. to EN 60529
IP 67 in accordance with EN 60529, achieved with piped air outlet. Replace with M5 adapters for
connection 3 and E threaded plug connectors (1434 000 Z2, 2 pieces required) for this purpose.
Weight: 220 g
Travel sensor: Integrated for direct mounting
Travel sensor version
Code 010 Code 030
Detection range: 0–10 mm 0–30 mm
Operating range: 0–10 mm 0–30 mm
Resistance: 1 kΩ 3 kΩ
Minimum travel sensor change: 3% (only relevant for initialisation)
Correlation - Travel sensor
1)
spindle/valve position
Retracted (top) ≙ 100% (valve open)
Extended (bottom) ≙ 0% (valve closed)
1) Design code 6960: Inversed mode of action compared with description
(Travel sensor signal inversed). For valves with inverted correlation.
www.gemu-group.com12 / 32GEMÜ 1434 µPos
