GEM 1434 mPos User Manual

7.6 Electrical data
7.6.1 Power supply
Supply voltage: 24 V DC (-5/+10%)
Power consumption: ≤ 4 W
Reverse battery protec-
tion:
yes
Duty cycle: Continuous duty
Electrical protection
class:
III
Electrical connection
type:
X1: Connector (A-coded), 1 x 5-pin M12
X3*: Plug (A-coded), 1 x 5-pin M12
* Only for travel sensor version with remote potentiometer (code S01).
7.6.2 Analogue input
Set value input: 4–20 mA (code A)
0–20 mA (code B)
0–10 V (code C)
Input type: passive
Input load: 0/4–20 mA:
50 Ω + approx. 0.7 V voltage drop due to reverse battery protection
0–10 V:
100 kΩ
Accuracy/linearity: ≤ ±0.3% of full flow
Temperature drift: ≤ ±0.3% of full flow
Resolution: 12 bit
Reverse battery protec-
tion:
yes
Overload proof: Yes (up to max. 30 V DC)
7.6.3 Analogue output
Note: The analogue output must be ordered using the ordering option "Option".
Actual value output: 4–20 mA (ordering option code A0)
0–20 mA (ordering option code B0)
0–10 V (ordering option code C0)
Output type: active
On-load current: 0–10 V: Max. 10 mA
Load resistor: 0/4–20 mA: Max. 600 Ω
Accuracy/linearity: ≤ ±1% of full flow
Temperature drift: ≤ ±0.5% of full flow
GEMÜ 1434 µPoswww.gemu-group.com 13 / 32
7 Technical data
