Resolution: 12 bit

Short-circuit proof: yes

Overload proof: Yes (up to max. 30 V DC)

7.6.4 Programming input initialisation (speed-AP function)

Input voltage: 24 V DC

Input current: 1.3 mA at 24 V DC

High level: >14 V DC

Low level: < 8 V DC

7.6.5 Travel sensor input (for travel length code S01 – remote potentiometer)

Supply

voltage U

P+

Typically 3.3 V DC

Resistance range of re-

mote potentiometers:

1 to 10 kΩ

Input voltage

range:

0 to UP+

Input resistance: 1.2 MΩ

Accuracy/linearity: ≤ ±0.3% of full flow

Temperature drift: ≤ ±0.3% of full flow

Resolution: 12 bit

www.gemu-group.com14 / 32GEMÜ 1434 µPos

7 Technical data
