ENG GEMAŞ STEAM GENERATOR AND CONTROL PANEL INSTRUCTIONS MANUAL V2.1
ASSEMBLY and INSTALLATION
The dimensions and instructions given in the assembly scheme and the wiring diagram must be
considered.
Unpack the Steam Generator. On the wall where you will install the generator, mark the hole
locations according to the given dimensions. There must be a distance of at least 50cm
between the ground and the generator lower level. At least 50 cm of space must be left on
both sides of the generator. There must be at least 30cm distance between the top level of the
generator and the ceiling.
Attach 8mm plastic dowels and screws to the holes you drill with 4 8mm drill bits. Unscrew the
4 bolts on the generator cover and open the cover. Attach the mounting holes on the generator
back plate to the bolts on the wall. Tighten the bolts so that there is no gap between the
generator and the wall.
Install 32 mm PPR pipe installation considering the distance between the device steam outlet
connection and the steam room. Make sure that the place where you will enter the steam room
is 10 cm above ground level and away from the seating areas. Make sure there are no
obstructions at least 50cm from the point where the pipe exits the steam room. When
installing, try to reach the steam room in the shortest way and creating as few elbows as
possible. If the elbows are unavoidable, keep the elbow angles wide. Do not use ready-made
90 ° elbows. Assemble 2 45 ° elbows. Make sure that the part of the installation that is parallel
to the floor creates a slope of at least 5% towards the steam room. If you do not create this
slope, it will prevent the condensate vapor formed in the pipe from advancing through the
installation and negatively affect the operation of the device. Fix the piping to the wall where
necessary. Secure the steam room inlet using suitable building material. Seal both sides of the
pipe using suitable building materials so that there is no gap. After making sure that the
installation is done properly, insulate the pipe with insulation tapes or pipes.
Connect the water inlet hose to the water valve and the water inlet of the generator. Connect
the drain hose to the drain pipe that goes underneath the device.
Install the Leakage Current Relay in a location next to the device and at least 150cm above the
ground. Connect the 5x4mm cable from the main board to the input of the residual current
relay. Connect the supply cable connected to the generator terminals to the output of the
residual current relay. Always connect the grounding end of the generator supply cable to the
grounding end coming from the panel with the terminal.
HEAT SENSOR: The temperature sensor must be mounted on the wall of the steam room at
least 150cm above the floor and 200cm above the floor. The temperature sensor must never
be in line with the steam outlet. Otherwise, since the sensor will detect the steam coming out
of the steam outlet, the room will stop the steam production without the actual set value.
AROMA PUMP: If you want to automatically pump essential oil into your steam room, you can
obtain the pump set related to this option from the manufacturer. If you have an existing
pump, or if you have a pump supplied by the manufacturer, you can connect the pump
electrical terminals to the terminal shown in the electrical connection diagram. Pump supply
terminal outputs are for 220V AC / 0,5A.
