Gemas Puriton On-line GSCol10 User Manual

GEMAŞ Genel Mühendislik Mekanik San.ve Tic.A.Ş.
İTOB Organize Sanayi Bölgesi 10001 Sok.No:28 Menderes/İZMİR TURKEY
Tel:0232 799 0 333 Fax:0232 799 0 330 www.gemas.com.tr info@gemas.com.tr
4
1 – PRODUCT FEATURES
• It produces chlorine in the salt concentration in the same proportion as the tear salinity.
• It has an automatic electrode cleaning feature against calcification.
• t has a long-lasting titanium electrode.
• It has an electrode life of 16,000 hours.
• It offers the opportunity to adjust to the optimum level by increasing or decreasing the pole
change time for cleaning the electrodes.
• It can be easily applied to the existing pool.
• The minimum recommended salinity is 4000ppm (4kg / m3).
• The device can also be used in seawater with 35000ppm.
•
1.1. Technical Specifications
GSCol10
GSCol20
GSCol30
Chlorine Production
10g / h
20g /h
30g /h
Supply Voltage
220V AC
220V AC
220V AC
Electrode Current
Max. 2A
Max. 4A
Max. 6A
Electrode Voltage
Max. 24V
Max. 24V
Max. 24V
Power consumption
50W
100W
150W
Max. Pool
Dimensions
Temperate
50m³
100m³
170m³
Tropical
35m³
65m³
110m³
Maximum Flow
450 l/ min
450 l/ min
450 l/min
Maximum Pressure
320 Kpa
320 Kpa
320 Kpa
Pressure drop
5 Kpa
5 Kpa
5 Kpa
Cell Type
Bipolar
Bipolar
Bipolar
Recommended Salt Concentration
4-35gr/l ppm
4-35gr/l ppm
4-35gr/l ppm
Cell Material
PMMA
PMMA
PMMA
Electrode Material
Titanium
Titanium
Titanium
Box sizes
Box Weight
