User guide – Plotter Flexipen 120/165
Plan
3
Chapter 1:
General specifications
1.1 Technical parameters:
Technical data Flexipen 120 Plotter Flexipen 165 Plotter
Voltage 220 v , 50 Hz 220 v , 50 Hz
Power supply 120 w 150 w
Overall dimensions ( L x l x H ) 1650 x 700 x 1200 mm 2100 x 700 x 1200 mm
Max. plotting speed 100 ÷ 600 mm/s 100 ÷ 800 mm/s
Maxim deviation between lines 0,1 mm 0,1 mm
Active plotting width 1200 mm 1600 mm
Maxim paper roll diameter
200 mm
200 mm
Internal diameter for paper roll 76 mm 76 mm
Pen preassure
0 ÷ 500 g
0 ÷ 500 g
Buffer 1 ÷ 4 MB*
Compression Storage
1 ÷ 4 MB*
Compression Storage
CPU dual CPU, parallel
processing
dual CPU, parallel
processing
Mechanical resolution 0,025 mm/step 0,025 mm/step
Language format HPGL ( PLT )
compatible
HPGL ( PLT )
compatible
Interface type RS-232 (serial port) RS-232 (serial port)
Origin coordinate Adjusted as needed Adjusted as needed
* Relative to the model
1.2 Technical specifications:
- Computer:
Minim: CPU P2-350Mhz, 64 MB RAM, 10 G HD, CD ROM drive;
Recommended: CPU P4-1,7Ghz, 256 MB RAM, 40 G HD, CD ROM drive.
- Operating System:
Windows 2003, Windows XP.
- Work environment moisture:
Temperature: 10 ÷ 30°C
Values out of range may cause low performances for the plotter;
Humidity: 35 ÷ 75%;
Avoid vibration, strong electromagnetic interference, and place of heavy dust.
Install the plotter to a plane surface which is stabile and larger than the plotter;
if the plotter is unstable, the plotting performance would be influenced.
