User guide – Plotter Flexipen 120/165
Plan
8
The P+ key (8) has the following functions:
In LEAVE state: moves to the left side the printing head (dolly);
In CONNECT state: increases pen pressure (the increasing pen pressure value
is shown on display).
The S+ key (9) has the following functions:
In LEAVE state: moves back the paper;
In CONNECT state: increases the pen speed;
The S- key (10) has the following functions:
In LEAVE state: moves advanced the paper
In CONNECT state: declines the pen speed;
• Flashing Caution Lights:
- Lighting Display: signals the fact that the plotter is plugged in.
- Flashing light on the up side of the Off/On button: indicates the plotter state.
Green light means the plotter is in the LEAVE state.
Red light means the plotter is in the CONNECT state.
- Flashing light from the up side of the Pause button: signs the fact that the plotter is
in the pause mode.
