Manual Part NO.: 119509-00 Rev. A
To use the 360 with the Advanced Control Cabinet, connect the 360’s audio cable to the
Cabinet’s corresponding speaker outputs (Figure 24).
Like the Advanced Control Cabinet, the Compact Control Cabinet can be used with the 360 by
connecting the 360’s audio cable to the Cabinet’s corresponding speaker outputs (Figure 25).
The exact wiring connections for these Control Cabinets will be determined by the 360 model
and stack configuration.
To learn more about Control Cabinets, contact your Sales Representative or consult the desired
Cabinet’s user manual.
