GENASYS 360 - 360 XL Specs

GENASYS 360
GENASYS INC.
Manual Part NO.: 119509-00 Rev. A
22
8.2 360XL Specs
Mechanical
One Emitter
Two Emitter
Four Emitter
Height
28.2 in (71.7 cm)
40.7 in (103.5 cm)
65.7 in (165.3 cm)
Diameter
32.4 in (82.3 cm)
Weight
121 lbs (54.9 kg)
182 lbs (82.6 kg)
304 lbs (137.9 kg)
Effective Projected
Area
713 in
2
(.460 m
2
)
1031 in
2
(.665 m
2
)
1668 in
2
(1.076 m
2
)
Conduit Inlet
1 in (11 ½ NPT) (11 BSP)
Torque
152 N m (max)
200 N m / 150 Ft lbs
Mounting Bolt
Recommendations
Galvanized M18 x 2.5 mm Class 8.8 ISO
Galvanized ¾ in – 10 per ASTM A325
Grade 5
Mounting Through
Holes
Four @ 2.06 cm diameter
Construction
Composite, Aluminum, Galvanized Structural Steel; RoHS Compliant
Temperature Range
-40° F to 140° F (-40° C to 60° C)
Acoustic
One Emitter
Two Emitter
Four Emitter
Maximum SPL @ 1 m
135 dBA
141 dBA
147 dBA
70 dB Coverage
Radius*
5833 ft (1778 m)
11640 ft (3548 m)
23225 ft (7079 m)
*Calculated in ideal environmental conditions.
