8.0 Specifications
8.1 360X Specs
Mechanical
One Emitter
Two Emitter
Four Emitter
Eight Emitter
Height
27.4 in
(69.6 cm)
39.5 in
(100.3 cm)
63.7 in
(161.8 cm)
111.9 in
(284.2 cm)
Diameter
32.4 in (82.3 cm)
Weight
110 lbs
(49.9 kg)
160 lbs
(72.6 kg)
260 lbs
(117.9 kg)
480 lbs
(217.7 kg)
Effective Projected
Area
710 in
2
(.458 m
2
)
1024.5 in
2
(.661 m
2
)
1658.5 in
2
(1.07 m
2
)
2915 in
2
(1.88 m
2
)
Conduit Inlet
¾ in (14 NPT) (14 BSP)
Torque
40 N m (max)
200 N m / 150 Ft lbs
Mounting Bolt
Recommendations
Galvanized M18 x 2.5 mm Class 8.8 ISO
Galvanized ¾ in – 10 per ASTM A325
Grade 5
Mounting Through
Holes
Four @ 2.02 cm diameter
Construction
Composite, Aluminum, Galvanized Structural Steel; RoHS Compliant
Temperature Range
-40° F to 140° F (-40° C to 60° C)
Acoustic
One Emitter
Two Emitter
Four Emitter
Eight Emitter
Maximum SPL @ 1 m
131 dBA
137 dBA
143 dBA
149 dBA
70 dB Coverage
Radius*
3681 ft
(1122 m)
7343 ft
(2238 m)
14656 ft
(4467 m)
28911 ft
(8912 m)
*Calculated in ideal environmental conditions.
