Gendex DenOptix QST - Panoramic and Cephalometric Imaging Plates

DenOptix QST
032-0265-EN Rev 13-8
Panoramic and Cephalometric Imaging Plates
1. Plastic mounting strips used to hold panoramic imaging plate onto the
carousel
2. Active imaging area, white color
3. Patient left (
L ) and right (R ) side indicators
4. General information that includes:
• Available from Gendex
• Date of manufacture
• Imaging plate size
• IP serial number
Panoramic Cephalometric
Front (Blue)
Rear (Black)
2
1
3
3
1
1
2 1
4
4
