System Operating Instructions
032-0265-EN Rev 1 4-7
12. Wrap the imaging plate around the
carousel and push the free end
under the edge of the other clip.
Pu
sh until you hear a click.
Panoramic shown.
13.
Open the carousel well
cover on the DenOptix QST
scanner a
nd insert the
carousel. Close the cover.
You are now ready to scan
your panoramic or cephalo-
metric imaging plate.
