5040A Operating Manual
GenelecDocumentD0078R001.CopyrightGenelecOy6.2008.Alldatasubjecttochangewithoutpriornotice
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
In the U.S. please contact:
Genelec Inc., 7 Tech Circle
Natick, MA 01760, U.S.A.
Phone +1 508 652 0900
Fax +1 508 652 0909
Email genelec.usa@genelec.com
www.genelec.com
In Sweden please contact
Genelec Sverige
Ellipsvägen 10B
P.O. Box 5521, S-141 05 Huddinge
Phone +46 8 449 5220
Fax +46 8 708 7071
Email info@genelec.com
AMPLIFIER SECTION
CONNECTORS
SYSTEM SPECIFICATIONS
5040A
Free field frequency response (± 3 dB) Main 35 Hz...85 Hz
LFE 35 Hz...120 Hz
Maximum short term sine wave SPL output
averaged from 40 to 85 Hz, measured in half
space at 1 meter
98 dB
Self generated noise level in half space at 1 m
on axis (A-weighted)
≤ 15 dB SPL
Driver,magneticallyshielded 165 mm (6
1
/
2
")
Weight 6.3 kg (13.9 lb)
Dimensions
Height
Diameter
251 mm (9
7
/
8
”)
305 mm (12”)
5040A
Amplifier short term output power
(Long term output power is limited by driver
unit protection circuitry)
40 W
AmpliersystemTHDatnominaloutput ≤ 0.05 %
Mains voltage 100, 120 or 230 V
Power consumption (average)
Idle
Full output
7 VA
70 VA
5040A
Main channels IN/OUT, LFE channel IN unbal-
anced female RCA connectors
Pin
Ring
+
gnd
Stereo IN 3.5 mm Jack female connector
Sleeve
Tip
Ring
gnd
Left channel
Right channel
Input impedance 10 kOhm balanced
Main channel OUT gain referred to IN 0 dB
CROSSOVER SECTION
5040A
Subsonic filter (18 dB/octave) below 35 Hz
Crossover frequency
(subwoofer/main channels)
85 Hz
LFE channel cutoff frequency 120 Hz
Midband rejection >400 Hz
>50 dB
Input level for 90 dB SPL output at 1 m -9 dBu at level control max
Sensitivity adjustment range 18 dB
Bass Roll-Off control operating range
in 2 dB steps
From 0 to -6 dB @ 35 Hz
Phase matching control in 90° steps From 0 to -270° @ 85 Hz
In China please contact:
Beijing Genelec Audio Co. Ltd.
Jianwai SOHO, Tower 12, Room 3304
39East3rdRingRoad,ChaoyangDistrict
Beijing 100022, China
Phone +86 10 5869 7915
Fax +86 10 5869 7914
