6 English
SYSTEM SPECIFICATIONS
Lower cut-off frequency, –6 dB: < 67 Hz
Upper cut-off frequency, –6 dB: > 25 kHz
Free field frequency response (± 2.5 dB): 74 Hz–20 kHz
Max. short term sine wave acoustic out-
put on axis in half space, averaged from
100 Hz to 3 kHz
at 1 m distance
at 0.5 distance
> 96 dB SPL
> 102 dB SPL
Maximum long term RMS acoustic output
in same conditions with IEC weighted
noise (limited by driver unit protection
circuit) @ 1 m:
> 91 dB SPL
Maximum peak acoustic output per pair
on top of console, @ 1 m distance with
music material:
> 105 dB
Self generated noise level in free field @
1 m on axis (A-weighted):
< 5 dB
Harmonic distortion at 80 dB SPL @
1 m on axis
Freq: 70…400 Hz
>400 Hz
< 3 %
< 0.5 %
Drivers:
Bass
Treble
76 mm (3
in)
cone
19 mm (
3
/
4
in)
metal dome
Weight: 1.5 kg (3.3 lb)
Dimensions:
Height including Iso-Pod™ table stand
Height without Iso-Pod™ table stand
Width
Depth
195 mm (7
11
/
16
in)
181 mm (7
1
/
8
in)
121 mm (4
3
/
4
in)
116 mm (4
9
/
16
in)
CROSSOVER SECTION
Input connector: XLR female 7 kOhm: pin 1 gnd,
pin 2 +
pin 3 -
Input level for 100 dB SPL output at 1 m: -6 dBu
(Sensitivity
-10 dB off)
Level control range relative to max output: -10 dB
(Sensitivity
-10 dB on)
Desktop control operating range: 0 to –4 dB
@ 200 Hz
Crossover frequency, Bass/Treble: 3.0 kHz
Bass Tilt control operating range in –2 dB
steps:
0 to –6 dB
@ 100 Hz
The ‘CAL’ position is with all tone controls and Sensitivity -10
dB function set to ‘off’
.
AMPLIFIER SECTION
Bass amplifier power with an 8 Ohm load: 25 W
Treble amplifier power with an 8 Ohm load: 25 W
Long term output power is limited by overload
protection circuitry
Amplifier system distortion at nominal output
THD+N:
< 0.08 %
Mains voltage: 100 - 240
V AC
Voltage operating range: ±10 %
Power consumption
Standby
Idle
Full output
<0.5 W
5 W
30 W
.
