Section 4

ENGINE DC CONTROL SYSTEM

Page 17

VOLTAGE

REGULATOR

TERMINAL BOARD

(TB1)

TERMINAL BOARD

(TB2)

START STOP RELAY

(SSR)

STARTER CONTACTOR RELAY

(SCR)

IDLE CONTROL

TRANSFORMERS

(ICT)

PRINTED CIRCUIT

BOARD

10 AMP FUSE (F1)

LOCATED IN REAR OF CONTROL PANEL

DIODE (D1)

RESISTOR (R1)

CONNECTOR

(C2)

CONNECTOR

(C1)

50 AMP CIRCUIT BREAKER

EXCITATION CIRCUIT

BREAKER (CB2)

10 AMP AUTO RESET

BREAKER (CB1)

BATTERY CHARGE RECTIFIERS

(BCR1 & BCR2)

CONTROL PANEL COMPONENT IDENTIFICATION
