Section 9
SPECIFICATIONS & CHARTS
Page 87
Flywheel Nut 150 ft. lbs.
Cylinder Head Bolts 22 ft. lbs.
Valve Cover Bolts 4.8-5.5 ft. lbs.
Rocker Arm Jam Nut 14 ft. lbs.
Ignition Coil 9 ft. lbs.
Intake Manifold 14 ft. lbs.
Exhaust Manifold 14 ft. lbs.
Stator Bolt 12 ft. lbs.
Rotor Bolt 30 ft. lbs.
Spark Plug 15 ft. lbs.
Starter Bracket To Block 18 ft. lbs.
TORQUE SPECIFICATIONS
M3-.5 PHILLIPS PAN HEAD SCREW INTO ALUMINUM 50 in. lbs.
M6-1 TAPTITE SCREW INTO ALUMINUM 9 6in. lbs.
M6-1 TAPTITE SCREW INTO WELDNUT 96 in. lbs.
M8-1.25 TAPTITE SCREW INTO ALUMINUM 18 ft. lbs.
TRIM TORQUE SPECIFICATIONS
