Section 7
DISASSEMBLY AND EXPLODED VIEWS
Page 69
ITEM QTY. DESCRIPTION
1 1 ADAPTOR, ENGINE
2 1 STATOR
3 1 ASSEMBLY, ROTOR W/FAN
4 1 CARRIER, REAR BEARING
5 1 EXHAUST MANIFOLD
6 1 MUFFLER
7 1 GASKET, EXHAUST
8 1 COVER, ALTERNATOR AIR INTAKE
9 1 BEARING
10 3 5/16 SPECIAL LOCK WASHER
11 1 SCREW IHHC 3/8-24 X 15.50 G5
12 4 SCREW IHHC M8-1.25 X 400 G8.8
13 1 BRACKET, ALT MOUNTING
14 4 SCREW HHTT #10-32 X 1.75
15 1 SCREW HHTT M8-1.2 X 20
16 1 ENGINE MOUNTING PLATE
17 6 RUBBER MOUNT
18 1 BATTERY CABLE, BLACK
19 1 EARTH STRAP 3/8X 3/8
20 1 CLIP-J VINYL COAT .625 ID
21 1 ASSEMBLY, BRUSH HOLDER
22 1 SCREW TAP-R #10-32 X 9/16
23 1 WASHER FLAT 3/8 ZINC
ITEM QTY. DESCRIPTION
24 5 WASHER LOCK 3/8
25 4 SCREW HHC 3/8-16 X 1-1/4 G5
26 4 WASHER FLAT 3/8-M10 ZINC
27 4 SCREW HHC M8-1.25 X 50 G8.8
28 21 WASHER FLAT 5/16 ZINC
29 4
NUT LOCK HEX M8-1.25 NYLON
INSERT
30 7 SCREW HHC M6-1.0 X 12
31 18 WASHER LOCK M8-5/16
32 12 NUT HEX 5/16-18 STEEL
33 2 SCREW TAPTITE 3/8-16 X 3/4 BP
34 1 SHIELD, MUFFLER HEAT
35 1 U-BOLT & SADDLE
36 4 SCREW SHC M8-1.25 X 18
37 1 PANEL, MUFFLER BOX BACK
38 1 PANEL, MUFFLER BOX END
39 3 SCREW HHTT M6-1.0 X 12
40 7 WASHER FLAT M6-1/4
41 7 WASHER LOCK M6-1/4
42 1 SPARK ARRESTOR SCREEN
43 1 RETAINER, SPARK ARREST SCREEN
44 1 SCREW HHTT M4-0.7 X 8
45 1 SHIELD, RUBBER MOUNT
46 2 SCREW HHTT M5-0.8 X 16
