Generac Power Systems ILC User Manual

Generac
®
Power Systems, Inc. 21
ITEM PART NO. QTY. DESCRIPTION
1 0E5531 1 ASSY.ENCL.NEMA 1 MTS 1-TVSS
0E5532 1 ASSY.ENCL NEMA 1 MTS 2-TVSS
2 0E5537 1 DECAL,POSITION IND/MTS SW.
3 0E4708 1 DECAL CIRCUIT BREAKER
4 0E4709 1 DECAL 1-TVSS
5 0E5359 0 / 1 DECAL,TVSS-GENERATOR
6 073619U 1 DECAL,TEST SEQUENCE/SW.INFO
7 0E5538 2 SWITCH PB NON-ILL. W/LATCH
8 0E2693B 2 CONTACT BLOCK NO
9 0E2693C 2 CONTACT BLOCK NC
10 0C2163B 2 LED RED WITH HOLDER
11 0C2163A 2 LED GRN WITH HOLDER
12 0E5361 1 CIRCUIT BREAKER,DIRECTORY CARD
13 0E5480 1 VINYL POUCH-C/B DIRECTORY CARD
14 0E4984 1 DECAL-WARNING/LIVE CIRCUIT
15 077228 1 DECAL-ENCLOSURE NOTE
16 0536210193 1 GROUND WIRE-ENCLSR DOOR
17 072164 1 MNL HNDL 6-1600A WN
18 0D4545 1 DECAL MANUAL OPERATION
19 0E4449 1 SUBPLATE - 200A 2P/3P
20 0E4987 1 DECAL-UL PANELBOARD
21 0E3717A 1 ASSY-NEUT BLK 250-400A W/TAP
22 0A9457 1 DECAL NEUTRAL
23 0C8884 1 TRANSFER SW-W 200A600V2P
0C8885 1 TRANSFER SW-W 200A600V3P
24 074672A 1 LMT SW-WN SEL & AUX2PL
25 0A9949 9 LUG SLDLSS 400-#4 X 1/4-20 CU7AL
26 0C7907H 2 COVER LUG 2P 150/200AMP
0C7907D 2 COVER LUG 3P 150/200AMP
27 0C8308 2 DECAL TERMINAL SHOCK HAZARD
28 090975 3 TRANSFORMER 240/40V 25VA
29 0E4999 1 / 2 SHIELD-1-TVSS MODULE
30 0D2572 2 FUSEBLOCK 30A 600V 3POS W/SQ
31 073590A 6 FUSE 5A X BUSS
32 0E4415G 1 DECAL FUSE RATING 5A 600V
33 0C3211G 2 SOCKET RELAY 8 PIN
34 0C3211R 2 RELAY DPDT 24VAC 10A 8PIN
35 0C3211H 4 SPRING RELAY RETAINING
36 0A9992B 2 BRACKET DIN TERM END
37 0C3996 FT RAIL DIN ALUMINUM BULK (SEE
DETAIL "C")
38 0E5178 1 ASSEMBLY NEUTRAL CABLE
39 091472 FT DUCT WIRING (SEE DETAIL "D")
40 091472A FT COVER WIRE DUCT 1 IN (REF. DETAIL
"D")
41 091477 13 RIVET WIRE DUCT MNT
42 063378 38 HOLDER CABLE TIE
43 063578 1 PLATE DATA - GTS
44 054199 1 DECAL DANGER HIGH VOLTAGE
45 0E5020 1 LUG SLDLSS #2-#8
46 067210A 1 DECAL GROUND LUG
47 0E4650 1 SUPPORT GLASTIC
48 0E4462 1 BRACKET 42 POS. PANELBOARD
49 0E4465 2 Z-RAIL 42 POS. PANELBOARD
50 0E4717 2 BUS SUPPORT ASSY P1-250
51 0E4469 2 NEUTRAL BAR 45 POS.
52 0E4466 1 INTEGRATED LOAD CENTER 42 POS.
1PH
ITEM PART NO. QTY. DESCRIPTION
0E4648 1 INTEGRATED LOAD CENTER 42 POS.
3PH
53 0E4464 2 SUPPORT DEAD FRONT 42 POS.
54 0E4463 1 DEAD FRONT 42 POS. PANELBOARD
55 0E4470 1 DECAL LOAD CENTER BRK 1-42
56 0E5010 1 DECAL-BREAKERS/BLANKS
57 056326 1 TRIM VINYL BLACK 1/8 GP 74" (52.8"
LG)
58 0E4649 1 DECAL (DANGER) ILC
59 0E4461 1 BRACKET,CIRCUIT BREAKER W/TVSS
60 0E4147 1 / 2 MTG TRACK BQ SIEMENS CB 2P
0E6002 1 / 2 MTG TRACK BQ SIEMENS CB 3P
61 0D5535 1 / 2 CB 0030A 2P 240V S BQ2 LL
0E5997D 1 / 2 CB 0030A 3P 240V S BQ3 LL
62 048766 1 / 2 BLOCK TERM 20A 2 X 6 X 1100V
63 023484D 2 BUSHING SNAP SB-875-11
64 0E4453 1 / 2 TVSS MODULE 1PH ATLANTIC SC.
0E4454 1 / 2 TVSS MODULE 3PH ATLANTIC SC
65 0E4460 1 BRACKET,CIRCUIT BREAKER
66 0E4458 2 CB 200A 240VAC 2P QJ22B200HL
0E4459 1 / 2 CB 200A 240VAC 3P QJ23B200HL
67 0E4985 1 DECAL-LINE CONNECTION
68 0E5143 1 SHIELD CIRCUIT BREAKER
69 0E4872 1 / 2 DECAL,TVSS ALARM CONTACTS
100 064101 7 NUT LOCK FL 3/8-16
101 022097 2 WASHER LOCK M6-1/4
102 038150 7 / 11 WASHER FLAT #8 ZINC 1-TVSS
103 022264 5 / 7 WASHER LOCK #8-M4 1-TVSS
104 022471 4 / 6 NUT HEX #8-32 STEEL 1-TVSS
105 025870 1 NUT WING 1/4-20
106 022127 2 NUT HEX 1/4-20 STEEL
107 0C2267 10 / 16 SCREW HHTT M5-0.8 X 12 BP 1-TVSS
108 074908 25 SCREW HHTT M5-0.8 X 10 BP
109 051713 3 WASHER FLAT M5
110 022152 3 WASHER LOCK #10
111 092980 1 SCREW PPHM M4-0.7 X 25
112 0C4896 9 SCREW FHM M8-1.25 X 20MM CR
113 067989 29 NUT LOCK FL M8-1.25 YEL CHR
114 026902 11 / 13 SCREW HHTT #8-32 X 1/4 CZ 1-TVSS
115 0C8275 4 SCREW PPHM DSEMS M4-7 X 10 ZNC
116 045764 10 SCREW HHTT M4-0.7 X 8 BP
117 0C2265 4 SCREW PHTT M4-0.7 X 12 ZYC
118 0A1661 4 / 6 RIVET POP .156 X .675 AL 1-TVSS
120 026850 2 WASHER SHAKEPROOF EXT 1/4 STL
121 092079 4 SCREW HHTT M6-1.0 X 25 BP
122 036962 8 SCREW PPHM 1/4-20 X 2-3/4
123 052857 1 NUT LOCK FL M6-1.0
124 022769 4 WASHER SHAKEPROOF INT #10
125 028430 4 NUT HEX #10-24 STEEL
126 036917 2 / 4 SCREW PPHM #8-32 X 3/8 1-TVSS
127 030795 2 SCREW HHC 5/16-18 X 1 G5
128 022259 2 NUT HEX 5/16-18 STEEL
129 022473 6 WASHER FLAT 1/4-M6 ZINC
130 022129 2 WASHER LOCK M8-5/16
QUANTITIES REQ'D FOR 1-TVSS / 2-TVSS
Section 8 — Exploded Views & Parts Lists
Generac ILC Type Transfer Switch
ILC Assembly- Drawing No. 0E4451-A (Page 4 of 4)
