SPECiFiCATiONS
1600WATT
EngineType........................ SingleCylinder,4-Stroke
EngineSize....................................... 99c0
StarterType...................................... Recoil
FuelCapacity/Type................... 0.69Gal(2.6L)/Unleaded
OilCapacity................................ 0.63Qt(0.6L)
Runtime at25%RatedLoad ...................... 5.7 Hours
SparkPlugType............................. NGKBPR7HS
SparkPlugGap..................................... 030"
DimensionsLx Wx H (in)...................... 22x 12x 18
WeightLb/kg.................................. 43.5/19.7
MaximumACOutput.............................. 1600W
SurgeACOutput................................. 1650W
ACVolts....................................... 120VAC
RatedACCurrent.................................. 13.3A
Frequency....................................... 60 Hz
THD............................................. 3.0%
InsulationClass.................................. ClassB
Outlets.............................. (2) 5-15R,(1) 12VDC
DCVolts........................................ 12VDC
RatedDCCurrent.................................... 5 A
2000WATT
EngineType........................ SingleCylinder,4-Stroke
EngineSize...................................... 127c0
StarterType...................................... Recoil
FuelCapacity/Type.................. 0.85Gal.(3.2L)Unleaded
OilCapacity................................ 0.63Qt(0.6L)
Runtime at25%RatedLoad ...................... 5.3 Hours
SparkPlugType.............................. NGKBPR6ES
SparkPlugGap..................................... 030"
DimensionsLx Wx H (in)...................... 22x 12x 18
WeightLb/kg.................................. 49.6/22.5
MaximumACOutput.............................. 2000W
SurgeACOutput................................. 2200W
ACVolts....................................... 120VAC
RatedACCurrent.................................. 16.7A
Frequency....................................... 60 Hz
THD............................................. 3.0%
InsulationClass.................................. ClassB
Outlets.............................. (2) 5-20R,(1) 12VDC
DCVolts........................................ 12VDC
RatedDCCurrent.................................... 5 A
NOTE:
Power output and runtime are influenced by many factors,
someofwhichare fuel quality,ambienttemperatureand engine
condition.Outputdecreases approximately 3.5% for each 1,000
feet abovesea level and 1% for every 10 degrees above60°F.
EMISSIONSINFORMAtiON
The Environmental Protection Agency (EPA) requires that your
generatorcomply with exhaustemissionstandards.Thisgenerator
is certified to meetthe applicableEPAemission levels.Additional
informationregardingthe requirementsset by EPAis as follows:
Themaintenancespecifications provided in this manualmust be
followed to ensurethat your enginecomplies with the applicable
emissionstandardsfor the durationof the engine'slife. Thisengine
is certifiedto operateon gasoline.Theemissioncontrolsystem on
your generatorconsists of the following:
• FuelMeteringSystem • IgnitionSystem
- Carburetor - Sparkplug
- FuelPump - Ignitionmodule
- FuelLines • ExhaustSystem
• Air InductionSystem
- Intakepipe/ manifold
- Air cleaner
The Emissions Compliance Period referred to on the Emissions
Compliance Label indicatesthe number of operating hours for
which the engine has been shown to meet Federalemission
requirements.
UNiT iDENTiFiCATiON (Figure2)
1. CarryingHandle:Lift the generatorby this handleonly.
2. SparkPlugCover:Allows access to the enginespark plug.
3. PrimerBulb:Usedto prime the fuel system for starting.
4. FuelTankCap:Accessto fuel tankfor filling.
5. Control Panel: location of generator controls and output
receptacles.
6. Air IntakeSlats: Allows for cooling airto enterthe housing.
7. Muffler: Lowers engineexhaust noise.
8. Choke:Coldenginestarting aid
9. Left Side ServiceCover: Allows access to air filter, fuel filter
and oil fill.
10. VentHoses: Hosesallow venting of the carburetor.
11. FuelShutoff:Controlsfuel supply to the carburetor.
12. Starter Rope:Pullropefor starting engine.
CONTROLPANEL(Figure3)
13. LOW OIL LEVELLED (yellow): Lights up when oil level is
belowsafe operatinglevelandthe engineshuts down.
14. OVERLOADLED(red):This LEDindicatesa systemoverload.
This LEDshould be usedin conjunctionwith the READYLED
which will flash an error code, seeNo. 15.
15. READY LED (green): Indicates output from the generator
unlessthere is a low oil or overloadcondition. In the eventof
a system overloadthe ReadyLED will provide an indication
of the overloadcondition.The indicationconsists of a series
of flashes separated by a pause. These indications are as
follows:
1 Flash-- Low Voltage.The unit has beenoverloadedto the
pointwherethe outputvoltagehas droppedto less
than IOOVAC.
