General Information
Owner’s Manual for MLT6SMD Light Tower 13
Section 2: General Information
Specifications
DESCRIPTION UNITS MLT6SMD
Engine
Make — Mitsubishi
®
Model — L3E-W464MLD
EPA Tier — Tier 4 Final
Horsepower—Prime hp (kW) 10.5 (7.8)
Horsepower—Standby hp (kW) 12.2 (9.1)
Operating Speed rpm 1,350/1,800
Displacement in
3
(L) 57.97 (0.95)
Cylinders quantity 3
Fuel Consumption—Full Load gph (Lph) 0.549 (2.078)
Fuel Consumption—Low Speed (Lights Only) gph (Lph) 0.19 (0.738)
Battery Type—Group Number — 24
Battery Voltage quantity per unit 12 (1)
Battery Rating cold-cranking amps (CCA) 440
Generator
Make — Marathon
®
Model — 331CSA3018
Type, Insulation — Brushless, F
Generator Set (Engine/Generator)
Output - Standby kW (kVA) 6.0 (6.0)
Output Voltage volts 120/240, single phase
Output Amperes 120V (240V) amperes 20 (25)
Frequency Hz Hertz 60
Power Factor percentage 1 (1Ø)
CSA Listed — Yes
Weights
Dry Weight lbs (kg) 1332 (604)
Operating Weight lbs (kg) 1602 (727)
Capacities
Fuel Tank Volume gal (L) 40.75 (154.26)
Usable Fuel Volume gal (L) 39.9 (151.04)
Coolant (including engine) qt (L) 4.5 (4.3)
Oil (including filter) qt (L) 5.0 (4.7)
Maximum Run Time
Operating with LED Lights Only hours 205
Operating with LED Lights and Export Power hours 73
