General Information
20 Owner’s Manual for MLT6SMD Light Tower
Control Panel
Figure 2-4. Control Panel
002986
120VAC OUTLET
BREAKER
DC CIRCUIT
BREAKER
CONTROL
POWER
240VAC
OUTLET
BREAKER
MAST LIGHT CIRCUIT BREAKERS MAST CIRCUIT
BREAKER
MAST UP
MAST DOWN
LOAD
SENSE
A B
C
D
L
K
J
H
G
E
F
