Generac Power Systems RD015 User Manual

Owner’s Manual for Stationary Diesel Generators 27
Section 5 Maintenance
5.1 — Component Locations
The side of the enclosure with the viewing window is identified as the rear of the generator set. The right and left sides
are identified by standing at the rear and looking towards the front of the unit.
Figure 5-1. Rear View
Figure 5-2. Right Side View
Main Circuit Breaker
Viewing
Window
Control Pad
and LCD Screen
7.5 Amp Fuse
and USB Port
Right SideLeft Side
Oil Level
Dipstick
Oil Filter
V-Belt
Air Filter
Oil Drain
Hose
Oil Fill Cap
