Maintenance
Owner’s Manual for Stationary Diesel Generators 29
5.2 — Access Panels
Access panels are located at both the front and sides of the enclosure.
5.2.1— Removal
1. Insert key into latch and rotate counterclockwise 1/2 turn. See Figure 5-5.
2. Raise panel using thumb latch.
5.2.2— Installation
1. Lower panel into position using thumb latch.
2. Insert key into latch and rotate clockwise 1/2 turn.
Figure 5-5. Access Panel Key
Key
Thumb Latch
