The Genesis GV60 Car Navigation System (CCIC2) is an integrated cockpit system designed to provide navigation, entertainment, and vehicle control functionalities. This quick reference guide outlines its features, operation, and safety precautions.

Function Description:

The CCIC2 system serves as the central interface for various vehicle functions, including:

Navigation: Provides detailed maps, route guidance, and location-based services.
Audio/Media Playback: Supports DAB (if equipped), FM, AM radio, USB media, and Bluetooth audio streaming. It also includes a voice memo function.
Vehicle Settings: Allows users to adjust various vehicle settings and preferences.
Connectivity: Features Wi-Fi (IEEE 802.11 a/b/g/n/ac) and Bluetooth (5.1) for seamless integration with external devices and networks.
User Profiles: Supports multiple user profiles (Driver 1, Driver 2, Guest) which can be selected using a finger scan sensor for personalized settings.
System Updates: The system can be updated with the latest maps and software via USB, using the Navigation Updater program available from the Genesis website (http://update.genesis.com).

Important Technical Specifications:

Power Supply: DC 12 V (Operation Power: DC 9 ~ 16 V)
Current Consumption: Max. 6 A (Dark Current average: 1 mA)
Operating Temperature: -20 ~ 70 °C
Storage Temperature: -40 ~ 85 °C
Dimensions (HeadUnit): 178 (W) x 70 (H) x 153.8 (D) mm
Weight (Headunit): 1.989 kg
Screen Size (Outline Dimension): 711.11(H) x 134.12(V) x 7.99(D) mm (Typ.), (W/O PemNut, W/Cover Glass 1.1T)
Resolution: 1920 x 720 (12.3”) / 1920 x 720 (12.3")
Operating Method: TFT, In Plane Switching (IPS), Active Matrix
Viewing Angle: 89/89/89/89 (L/R/U/D)
Internal Lighting: LED
Wi-Fi (If equipped):
- Frequency Range/Output Power: 2.4 GHz / Max. 23.58 dBm, 5 GHz / Max. 10.21 dBm
Radio:
- AM: Tuning Range: 522 ~ 1620 Khz, Usable Sensitivity: 35 dBuV, SNR Ratio: 45 dB
- FM: Tuning Range: 87.5 ~ 108.0 Mhz, Usable Sensitivity: 10 dBuV, SNR Ratio: 50 dB
- DAB (If equipped): Tuning Range: 174.928 ~ 239.200 Mhz, Min. Sensitivity: -100 dBm, Adjacent Channel Selectivity: 60 dBc, Far Off Selectivity: 60 dBc
Bluetooth:
- Supported Profile: HFP 1.7/A2DP 1.3/AVRCP 1.6/PBAP 1.2/MAP 1.2/SPP 1.2/BIP 1.2
- Supported Bluetooth Specification: 5.1
- Frequency Range/Output Power: 2402 ~ 2480 Mhz / Max. 2.48dBm
- Number of Channels: 79

Usage Features:

The system offers intuitive control through a combination of physical buttons, a controller, and a touchpad.

Front Seat Control Key:

① /VOL wheel button: Briefly press to turn media/radio on/off. Press and hold to turn on or off the display and sound. Turn up/down to adjust volume.
② BACK button: Briefly press to move to the previous screen. Press and hold to move to the home screen.
③ HOME button: Briefly press to move to the home screen. Press and hold to move to the map screen.
④ Finger scan sensor: Used to select user profiles or convenience features.
⑤ TUNE button:
- Radio (DAB/FM): Turn up/down to change searched station.
- Radio (AM): Turn up/down to increase/decrease frequency by one step.
- Media/Voice memo: Turn up/down to search for a file; press to play the displayed file.
- Navigation: Turn up/down to change map scale.
⑥ MENU button: Displays a pop-up menu for each mode when pressed briefly.
⑦ Controller: Used to move and select menus, input handwriting, and change map scale.

Steering Wheel Remote Control (Right):

① (Voice recognition) button:
- When pressed shortly: Activates voice recognition mode.
- When pressed and held: Activates voice recognition mode of the connected phone projection device; press and hold to cancel voice recognition.
② (Custom) button: User may select and use a desired feature with this button. Press and hold to move to the custom button settings screen.
③ + / - tumbler button: Slides up/down to adjust the volume.
④ (MUTE) button: Presses the tumbler to turn mute on/off.
⑤ (Bluetooth call) button:
- When pressed shortly: Searches for new Bluetooth phones or connects to registered phones if Bluetooth is not connected.
- If Bluetooth is connected:
  - In call waiting screen: Displays call history screen.
  - In call history screen: Makes a call to last called number.
  - In phone entrance screen: Enters the last call number.
  - In phone reception alert screen: Answers the phone call.
  - If in call: Ends the call.
⑥ MODE button:
- When pressed shortly: Selects a mode from Bluetooth audio, DAB (if equipped)/FM, AM, USB music, USB video, phone projection, or sounds of nature.
- When pressed and held: Moves to the mode button (steering wheel) settings screen.

Steering Wheel Remote Control (Left):

① Custom button: User may select and use a desired feature with this button. Press and hold to move to the custom button settings screen.
② button: For details, refer to the vehicle instruction manual.
③ Tumbler button: Press or slide up/down the button to change the gauge style and view mode displayed on the cluster screen.

Optical Touchpad (on the left steering wheel remote control):

When swiped:
- Radio: Moves to the previous or next frequency saved.
- Media/Voice memo: Plays the previous or next file.
When dragged:
- Radio: Changes the frequency until the user lifts their finger, then searches for the frequency.
- Media/Voice memo: Rewinds or fast-forwards the file (except for Sounds of nature).

Turning the System On/Off:

To turn on: Press the engine start button. The system will boot up and display a safety warning page. Select language and user profile (Driver 1, Driver 2, or Guest), then press [Confirm].
To turn off: Press and hold the [G/VOL] wheel on the front seat control key.
To turn on again: Press the [G/VOL] wheel on the front seat control key.

Using Controller and Touchpad:

Rotate controller: Clockwise/counterclockwise to move through lists in the menu. Operates zoom in/out on the map screen.
Swipe on touchpad: Up/down/left/right to switch menus.
Press touchpad: Selects menu, enters characters via handwriting input.
Push controller: Up/down/left/right/diagonal to move menu and map location. Push and hold to scroll the map.

Maintenance Features:

System Updates: Regular updates are required for software corrections, new functions, and map updates. Updates can take up to 1 hour depending on data size. It is crucial not to turn off power or eject the USB during the update process to prevent failure.
Troubleshooting: The manual provides solutions for common issues such as power failure (check fuse, device connection), system not playing (check battery, contact service center), low video quality (adjust brightness), sound not working (adjust volume, check connection), USB not working (check USB damage, format, contamination, direct connection, standard USB type, supported file formats).
Safety Precautions:
- Always operate the vehicle safely and avoid distractions while driving.
- Do not change settings or functions while driving; pull over safely.
- Certain functions are disabled unless the parking brake is on.
- Do not remove the cover or back of the product to avoid electric shock; refer servicing to qualified personnel.
- Do not expose the product to water, rain, or moisture to prevent fire or electric shock.
- Keep the volume low enough to hear outside sounds while driving.
- The driver should not watch the monitor while driving, as this can lead to accidents.
- Do not drop the device or subject it to heavy impacts.
- The system cannot be operated while booting up.
- A safety warning page is displayed every time the ACC is turned on; read and comply with these warnings.
