Genesis CCIC2 - 12 Troubleshooting; Specification

13
English
Specication
Common
Power Supply DC 12 V
Operation Power DC 9 ~ 16 V
Current
Consumption
Max. 6 A
Dark Current
(average)
Max. 1 mA
Operating
Temperature
-20 ~ 70 °C
Storage
Temperature
-40 ~ 85 °C
Dimensions
(HeadUnit)
178 (W) x 70 (H) x 153.8 (D)
mm
Weight (Headunit) 1.989 kg
Front
Monitor
Screen Size
(Outline Dimension)
711.11(H) x 134.12(V) x 7.99(D)
mm (Typ.), (W/O PemNut,
W/Cover Glass 1.1T)
Resolution
1920 x 720 (12.3”)/
1920 x 720 (12.3”)
Operating Method
TFT, In Plane Switching (IPS),
Active Matrix
Viewing Angle 89/89/89/89 (L/R/U/D)
Internal Lighting LED
Wi-Fi (If
equipped)
Standard IEEE 802.11 a/b/g/n/ac
Frequency Range/
Output Power
2.4 GHz / Max. 23.58 dBm
5 GHz / Max. 10.21 dBm
Radio
AM
Tuning Range 522 ~ 1620 Khz
Usable Sensitivity 35 dBuV
SNR Ratio 45 dB
FM
Tuning Range 87.5 ~ 108.0 Mhz
Usable Sensitivity 10 dBuV
SNR Ratio 50 dB
DAB (If
equipped)
Tuning Range 174.928 ~ 239.200 Mhz
Min. Sensitivity -100 dBm
Adjacent Channel
Selectivity
60 dBc
Far Off Selectivity 60 dBc
Bluetooth
Supported Pro󳝌le
HFP 1.7/A2DP 1.3/
AVRCP 1.6/PBAP 1.2/
MAP 1.2/SPP 1.2/BIP 1.2
Supported
Bluetooth
Speci󳝌cation
5.1
Frequency Range/
Output Power
2402 ~ 2480 Mhz
Max. 2.48dBm
Number of
Channels
79
Specication
