5-48
Driving your vehicle
An AWD vehicle should not be tested
on a 2WD roll tester. If a 2WD roll
tester must be used, perform the fol-
lowing procedure:
1. Check the tire pressures recom-
mended for your vehicle.
2. Place the rear wheels on the roll
tester for a speedometer test as
shown in the illustration.
3. Release the parking brake.
4. Place the front wheels on the tem-
porary free roller as shown in the
illustration.
Limited Slip Differential refers to a
feature equipped with a mechanism
that controls the differential functions
of the wheels in the rear differential.
The Limited Slip Differential helps
improve handling performance when
circling at high speed.
Keep away from the front of the
vehicle while the vehicle is in
gear on the dynamometer. The
vehicle can jump forward and
cause serious injury or death.
WARNING
OIK057035
Roll Tester (Speedometer)
Temporary Free Roller
LLIIMMIITTEEDD SSLLIIPP DDIIFFFFEERREENNTTIIAALL
((IIFF EEQQUUIIPPPPEEDD))
Never run wheels with one of
them lifted by the jack. It is
extremely dangerous for a vehi-
cle equipped with Limited Slip
Differential.
WARNING
