7-3
7
Maintenance
EENNGGIINNEE CCOOMMPPAARRTTMMEENNTT
OIK077001/OIK017007
■■
Lambda 3.3 T-GDI
■■
Theta 2.0 T-GDI
1. Engine coolant reservoir
2. Radiator cap
3. Brake/Clutch fluid reservoir
4. Air cleaner
5. Engine oil dipstick
6. Engine oil filler cap
7. Windshield washer fluid reservoir
8. Fuse box
❈ The battery is in the trunk.
The actual engine compartment in the vehicle may differ from the illustration.
