7-58
Maintenance
Headlamp (High)
1. Open the hood.
2. Disconnect the negative battery
cable.
3. Remove the headlamp bulb cover
by turning it counterclockwise.
4. Disconnect the headlamp bulb
socket-connector.
5. Remove the bulb-socket from the
headlamp assembly by turning the
bulb-socket counterclockwise until
the tabs on the bulb-socket align
with the slots on the headlamp
assembly.
6. Install a new headlamp bulb into
the bulb-socket.
7. Push the bulb-socket into the
headlamp assembly and turn the
bulb-socket clockwise.
8. Connect the headlamp bulb sock-
et-connector.
9. Install the headlamp bulb cover by
turning it clockwise.
Headlamp (Low)
1. Disconnect the negative battery
cable.
2. Remove the service cover (1)
under the wheel housing by push-
ing out the retainer clip with a slim
tool. If it is difficult to remove the
service cover because of the tire,
steer the tire inward.
OIK077062N
OIK077073N
To Next Page
