09
9-49
Instrument panel (Driver’s side fuse panel)
Fuse Name
Fuse Rating Circuit Protected
MULTI MEDIA1
20A
[W/O ISG] Fuse - F11, F12
[With ISG] Low DC-DC Converter (Audio)
AIR BAG1
15A SRS Control Module
ROOM LAMP
10A
Overhead Console Lamp, Center Room Lamp, Room
Lamp Vanity Lamp Switch LH/RH, Luggage Lamp LH/
RH Glove Box Lamp, Driver/Passenger Foot Lamp
STOP LAMP
10A IBU, Stop Lamp Switch
CLUSTER
10A Instrument Cluster, Head-Up Display
E-SHIFTER2
10A Electronic ATM Shift Lever
IBU3
10A IBU
MULTI MEDIA3
10A
[With ISG] Instrument Cluster, Head-Up Display,
A/C Switch Front Wireless Charger, Around View
Monitor [W/O ISG] Around View Monotor
MULTI MEDIA2
15A Audio
MEMORY1
10A
A/C Control Module, A/C Switch, Security
Indicator Head-Up Display, Power Tail Gate Unit, Power
Trunk Module [W/O ISG] Instrument Cluster
IBU4
10A IBU
E-SHIFTER1
10A Electronic ATM Shift Lever
AIR BAG IND.
10A Instrument Cluster, Overhead Console Lamp
IBU1
15A
IBU, Driver/Passenger Smart Key Outside
Handle, Driver/Passenger Power Outside Mirror
DRIVER
DR MODULE
10A
Driver Door Module, Driver/Passenger Power Outside
Mirror
E-CALL
10A Emergency Call Module
MODULE2
10A IBU
MODULE3
10A Driver Door Module, Stop Lamp Switch
To Next Page
