Rear fuse box panel
Fuse Name Fuse Rating Circuit Protected
DCU2 15A Dosing Control Module
DCU3 15A Dosing Control Module
REAR WIPER 15A Wipre RR Relay, Rear Wiper Motor
ECS 15A ECS Unit
POWER TRUNK 30A Power Trunk Module, Power Tailgate Unit
DCU1 15A Dosing Control Module
FUEL PUMP 20A Fuel Pump Relay
HEAT MIRROR 10A A/C Switch, Driver/Passenger Power Outside Mirror
AMP2 25A AMP
REAR S/HEAT 20A Rear Seat Warmer Control Module
AMP1 30A
[W/O ISG] Fuse - F9
[With ISG] Low DC-DC Converter (AMP)
IG1 15A PCB Block (IG1 Relay)
ACC 30A ICU Junction Block (Fuse - F32, F40, F54)
B+1 40A
ICU Junction Block
(IPS5, IPS6, IPS7, IPS8, IPS9, IPS10, Fuse - F20, 30F)
B+2 40A ICU Junction Block (IPS1, IPS2, Fuse - F15, F39)
REAR HEATED 30A Rear Heated Relay
