Maintenance
9-60
Battery box fuse panel
Fuse Name Fuse Rating Circuit Protected
B+1 100A
Rear Sub Junction Block
(ACC Relay, Fuse - F7, F12, F13, F16, F17)
B+2 100A
Rear Sub Junction Block
(DCU Relay, Fuse - F3, F5, F4, F11, F15)
START 40A
E/R Junction Block (Fuse - F3),
PCB Block (Fuse - F3, F9)
AMS 10A Battery Sensor
