11.5 B2C & Teapot Machines
H
1
2
3
4
Pipe No Diameter Length
1 6 mm I.D. x 10 mm O.D. 170 mm
2 6 mm I.D. x 10 mm O.D. 160 mm
3 6 mm I.D. x 10 mm O.D. 190 mm
4 8 mm I.D. x 13 mm O.D. 360 mm
H = Hot Water Dispense Pipe
Technical Manual
