SETTmNGCONTACT REVERSE
FUNCTmON
Limit Switchand [orce Adjustments _/ust be completed
beforecheckingthe contact reversetunction (Figure A,S).
A OpengaragedoorusingWalIConsole.
B Laya 2"x4"boardflatin centerofdoorway.
C CIosedoorusingWalIConsob,
D Checkthatdoorstopsandreverses
within 2secondsafterit
contactsboard:
Ifdoordoesnot reverse,decrease
CloseForceuntil doorreverses.
Ifdoorstilldoesnotreverse,move
CLOSELimitSwitchtowarddoor.
E CheckSafe-T-Beam®Systemoperation:
/
Ifbeamisblocked,doorwill _.._
2"
X
4" board
notdose, / _ [aidfiat
Figure A-S Checking Contact Reverse
The door must contactthe 2" x 4" board beforethe
Carriageactivatesthe CloseLimit Switch. if not,readjust
the Cbse Limit Switch.
f
Transmitter Complance Statement
Transmitters compUy with ai United Statesand Canadian UegaUrequirements
as of the date of manufacture. No warranty is made that they compUywith al
UegaUrequirements of any other jurisdiction If transmitters are to be used in
another country, the importer must determine compliance with any Uocal
Uawsand reguBtions which may differ from United States and Canadian
requirements prior to use,
Lostransmisores cumpbn con todas masregbmentaciones legales de los
EstadosUnidos y del Canada, en la fecha de fabricaci6n, Ninguna garantia
se da que cumplan con todas asreglamentadones legales de ninguna otra
judsdicci6n. Si los transmisores se van a uttizar en otro pais, el importador
debe determinar si cumplen con las reglamentaciones y meyeslocales que
puedan set diferentes alas reglamentaciones de los Estados Unidos y de[
Canada, antes de usar los mismos.
Les#metteurs sont conformes _ la r#glementation am#ricaine et canadienne
compter de bur date de fabrication. Aucune garantie n'est stipul@
indiquant qu'ils sont conformes £ toutes les prescriptions juridiques d'autres
autorit#s.Si les emetteurs sont utlises dans d'autres pays,t incombe
I'importateur d'en d#terminer leur conformit# aux loiset r_gmeslocales
pouvant diff#rer de celes des Etats-Unis et du Canada avant route
utilsation desdits #metteurs,
Sendeger£te entsprechen allen gesetzlchen Bestimmungen in den USAund
Kanada zum Zeitpunkt der Herstelung.Wir ubernehmen keine
Gew£hrbistung for die Einhamtungaler gesetzlchen Bestimmungen in
anderen Landern.Solen Sendegerate in anderen L£ndern eingesetzt werden,
so muss der Importeur vor dem Gebrauch sicherstelen, dass die Sendeger£te
auch solchen Iokalen Bestimmungen entsprechen, welche yon den
Bestimmungen der USAund Kanadas abweichen,
£%AnlEql! n@_t _lqq lqOtl_,t _t@ I_@ t711tot 1£ 1¥_,t!t
_401 o X [E_-O xtOl
ACCESSORIES
PIOGIAIIIIINGTHE
_EMOTE CONTIOLS
, EachRemoteControl must be programmed
separately.
, TheRemoteControlswill not causethe door
Openerto closethe garagedoor if the Safe-T-
Beam¢_Systemismaltunctioning.
, When programming the RemoteControls,they
must be at east24 from the AntennaWire.
, if the red LearnIndicatorLight blinks
approximately 4 times persecond,
programming hasstopped. If programming
hasstopped,repeatthe above steps.
, EachButton on a 2or 3 Button RemoteControl
isfor adifferent Opener.Youcannot use more
than one Button per Remote,per Opener.
, A maximumof sevenRemoteControlsor
Wireless Keypadscan be stored into the.
Receiverat one time. If aRemoteControl
becomeslost,or if you want to delete a Remote
Control or WirelessKeypad,see To EraseAll
ReceiverMemory."
A Toprogramone Button of a RemoteControl (Figure _A-I):
Locate Learn Button and Learn Indicator Light
on back side of Power Head under the Lens
(Figure MA-2).
Pressand release _earn Button. Red Learn
Indicator Light will blink 2 times per second.
PressRemote Control Button once within 30
seconds. Red Learn Indicator Light will stay lit.
PressRemote Control Button again. Red Learn
Indicator Light will go out, indicating that
memory is stored.
I Programeach additional Remoteusing stepg above
(upto sevenremotes).
ziWAILING:
_g garagedoormaycauseseriousinjuryo_
death,
• Keeppeopleclearofopeningwhiledoor ismoving,
° Donot a/ow childrento piaywith the Remote
Controls,
IftheSafetyReversedoesnotwork properly:
• Closethe dooranddisconnectthe Openerusing
theEmergencyReleaseCord.
° Donot usethedoor Opener.RemoteControB.or
WirelessKeypad.
Manualsbeforeattemptinganyrepars.
8 For Help, call 1-800-35-GENIE or visit www.genbcompany.com
