Genie S-45 TRAX Service Manual

Section 4 • Repair Procedures
4 - 10 S-40 • S-45 • S-40 TRAX • S-45 TRAX Part No. 826364
February 2014
S-40 Models:
2 Tag, disconnect and plug the hydraulic hoses
from the platform rotator. Cap the fittings on the
rotator.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to squirt
or spray.
S-45 Models:
3 Tag and disconnect the hydraulic hoses from
the "V1" and "V2" ports on the counterbalance
valve manifold located on the platform rotator
and connect them together using a connector.
Cap the fittings on the manifold.
4 Support the platform leveling arms and platform
mounting weldment with an appropriate lifting
device, but do not apply any lifting pressure.
PLATFORM COMPONENTS
All Models:
5 Remove the six mounting bolts from the
platform mounting weldment. Remove the
center bolt and slide the platform mounting
weldment off of the platform rotator.
Crushing hazard. The platform
mounting weldment could become
unbalanced and fall if it is not
properly supported.
6 Support the platform rotator with an appropriate
lifting device. Do not apply any lifting pressure.
7 Support the platform leveling slave cylinder.
Protect the cylinder rod from damage.
8 Remove the pin retaining fasteners from both
the slave cylinder rod-end pivot pin, and the
rotator pivot pin.
9 Use a soft metal drift to drive both pins out, then
remove the platform rotator from the machine.
Crushing hazard. The platform
rotator could become unbalanced
and fall if it is not properly
supported.

Genie S-45 TRAX Specifications

General

Gradeability	45%
Fuel Type	Diesel
Maximum Working Height	15.72 m
Maximum Platform Height	13.72 m
Lift Capacity	500 lb (227 kg)
Turning Radius	10 ft 8 in (3.25 m)
Turning Radius (Outside)	10 ft 8 in (3.25 m)
Machine Length	7.55 m
