Genie S-45 TRAX Service Manual

3 - 20 S-40 • S-45 • S-40 TRAX • S-45 TRAX Part No. 826364
October 2014Section 3 • Scheduled Maintenance Procedures
B-4
Perform Engine Maintenance -
Perkins Models
Engine specifications require that this procedure be
performed every 250 hours.
Proper engine maintenance, following the engine
manufacturer's maintenance schedule, is essential
to good engine performance and service life. Failure
to perform the maintenance procedures can lead to
poor engine performance and component damage.
• Engine belts - check/adjust
Required maintenance procedures and additional
engine information are available in the
Perkins 400 Series Operation Manual
(Perkins part number TPD 1443S).
Perkins 400 Series Operation Manual
Genie part number 94890
B-5
Check the Oil Cooler and
Cooling Fins - Deutz D2011L03i
Models
Engine specifications require that this procedure be
performed every 250 hours or quarterly, whichever
comes first.
Maintaining the oil cooler in good condition is
essential for good engine performance. Operating a
machine with a damaged oil cooler may result in
engine damage. Also, restricting air flow through
the oil cooler will affect the performance of the
cooling system.
Bodily injury hazard. Do not
inspect while the engine
is running. Remove the key to
secure from operation.
Burn hazard. Beware of hot engine
components. Contact with hot
engine components may result in
severe burns.
Oil cooler:
1 Remove the safety pin from the engine pivot
plate latch.
Note: The engine pivot plate latch is located under
the engine turntable pivot plate at the counterweight
end of the machine.
CHECKLIST B PROCEDURES

Genie S-45 TRAX Specifications

General

Gradeability	45%
Fuel Type	Diesel
Maximum Working Height	15.72 m
Maximum Platform Height	13.72 m
Lift Capacity	500 lb (227 kg)
Turning Radius	10 ft 8 in (3.25 m)
Turning Radius (Outside)	10 ft 8 in (3.25 m)
Machine Length	7.55 m
