Genie S-45 TRAX Service Manual

Section 4 • Repair Procedures
Part No. 826364 S-40 • S-45 • S-40 TRAX • S-45 TRAX 4 - 9
February 2014
PLATFORM COMPONENTS
9 Remove the external retaining fastener from the
barrel-end pivot pin.
10 Use a soft metal drift to drive the rod-end pivot
pin out.
11 Use a soft metal drift and drive the barrel-end
pin out.
12 Carefully pull the cylinder out of the boom.
Component damage hazard. Hoses
can be damaged if they are kinked
or pinched.
How to Bleed the Slave Cylinder
Note: Do not start the engine. Use auxiliary power
for this procedure.
1 Raise the primary boom to a horizontal position.
2 Move the platform level toggle switch up and
down through two platform leveling cycles to
remove any air that might be in the system.
2-2
Platform Rotator
The platform rotator is a hydraulically activated
helical gear assembly used to rotate the platform
160 degrees.
How to Remove the
Platform Rotator
Component damage hazard. Mark
the platform mounting weldment
and the rotator flange before
removing the platform mounting
weldment. The platform mounting
weldment must be replaced in the
exact same position on the rotator
flange as it was before removal. If
a new rotator is installed or the
rotator is disassembled, proper
alignment can be achieved by
rotating the rotator all the way to
the left and then installing the
platform mounting weldment all
the way in the left position.
Note: When removing a hose assembly or fitting,
the O-ring on the fitting and/or hose end must be
replaced and then torqued to specification during
installation. Refer to Section Two, Hydraulic Hose
and Fitting Torque Specifications.
1 Remove the platform and platform support.
