Genie Z-34/22 Service Manual

Service Manual April 2016
Maintenance Inspection Report
16 Z-34/22 Bi-Energy Part No. 139234
Model
Serial number
Date
Hour meter
Machine owner
Inspected by (print)
Inspector signature
Inspector title
Inspector company
Instructions
• Make copies of this report to use for
each inspection.
• Select the appropriate checklist(s) for
the type of inspection(s) to perform.
Daily or every
8 hours A
Quarterly or every
25
0 hours
A + B
Semi
-annually or
every 50
0 hours
A + B + C
Annually or
every
100
0 hours
A + B + C + D
Two
-year or
every
200
0 hours
A + B + C + D + E
• Place a check in the appropriate box
after each inspection procedure is
completed.
• Use the step-by-step procedures in
this section to learn how to perform
these inspections.
• If any inspection receives an "N," tag
and remove the machine from service,
repair and re-inspect it. After repair,
place a check in the "R" box.
Legend
Y = yes, acceptable
N = no, remove from service
R = repaired
Checklist A
Y N R
A-1 Inspect the manuals
and decals
A-2 Pre-operation
inspection
A-3 Function tests
A-4 Engine maintenance
A-5 Generator belts
Perform after 40 hours:
A-6 30-day service
Perform after 50 hours:
A-7 Engine maintenance
Perform every 75 hours:
A-8 Engine maintenance
Perform every 100 hours:
A-9 Engine maintenance
A10 Rotation Bearing
Perform after 150 hours:
A-11 Drive hub oil
Perform every 200 hours:
A-12 Engine maintenance
Checklist B Y N R
B-1 Exhaust system
B-2 Battery
B-3 Electrical wiring
B-4 Tires and wheels
B-5 Brake configuration
B-6 Drive hub oil
B-7 Glow plugs
B-8 Engine RPM
B-9 Ground control
override
B-10 Platform leveling
B-11 Engine idle select
B-12 Drive brakes
B-13 Drive speed - stowed
B-14 Drive speed - raised
or extended
B-15 Alarm package
B-16 Electrical contactors
B-17 Fuel and hydraulic
tank cap venting
B-18 Hydraulic oil analysis
B-19 Emergency power
Perform every 400 hours:
B-20 Engine maintenance
Comments

Genie Z-34/22 Specifications

General

Lift Capacity	500 lbs
Platform Rotation	180°
Turntable Rotation	355° non-continuous
Stowed Height	6 ft 6 in
Vertical Jib Rotation	139°
Fuel Type	Diesel
Horizontal Reach	22 ft 3 in
Power Source	Diesel
Drive Speed - Stowed	3.5 mph
