Genie Z-34/22 Service Manual

April 2016 Service Manual
Engines
Part No. 139234 Z-34/22 Bi-Energy 83
6-1
Timing Adjustment
Complete information to perform this procedure is
available in the Kubota Z482-E.
Kubota Z482-E3B Operator's Manual
Genie part number
139420
6-2
RPM Adjustment
Refer to Maintenance Procedure in the appropriate
Service or Maintenance Manual for your machine,
Check and Adjust the Engine RPM.
6-3
Engine Drive Pulley
How t o R emov e t he E ngi ne D rive P ulley
How to Remove the Engine Drive
Pulley
1 Remove the engine pivot plate latch retainer.
2 Open the engine pivot plate latch and swing
the engine out away from the machine to
access the engine drive pulley.
3 Loosen the tension adjustment bolt on the
generator.
4 Pull the generator away from the machine and
remove the belts from the generator pulley.
5 Remove the 3 bolts that attach the engine
drive pulley to the shaft bushing.
6 Install the same 3 bolts that were removed in
step 5 into the threaded holes of the engine
drive pulley.

Genie Z-34/22 Specifications

General

Lift Capacity	500 lbs
Platform Rotation	180°
Turntable Rotation	355° non-continuous
Stowed Height	6 ft 6 in
Vertical Jib Rotation	139°
Fuel Type	Diesel
Horizontal Reach	22 ft 3 in
Power Source	Diesel
Drive Speed - Stowed	3.5 mph
