STEP 11: Install Aluminum Platforms
39
1. Insert the (4) M5×14 screws through the holes of the polished rod holders and align them with the
corresponding holes of the original aluminum platform and the sheet metal connector, then screw them
in and tighten.
2. Insert the (4) M5×8 screws through the corresponding holes of the sheet metal connector, and screw
them into the threaded holes of the original aluminum platform then tighten.
Original Aluminum Platform
Sheet Metal
Connector
(4) M5×8 Flat Head Screw
(4) M5×14 Flat Head Screw
Attention to the Position
of the Gap Here
To Next Page
