110EZiSYSTEM, Functional Checks
Checking the
performance
The purpose of the following procedure is to verify the performance of the Transmitter. It is
important that the test is conducted away from areas of electromagnetic interference.
1. Plug the Transmitter’s cable set into the connection socket.
2. Connect the black and red cable clips together, ensuring good metal to metal contact.
3. Hold down Frequency Control Button and switch the Transmitter on. Note, Hold the
frequency control button down until the Extended Self Test has commenced.
4. Observe the displayed output:
5. The transmitter will display the outcome.
Induction Mode Test Mode Display: Induction LED illuminated.
Frequency Display: Frequency LED illuminates showing the
frequency on test.
Mode Display: Induction LED off.
Connection Mode Test Mode Display: Connection LED illuminated.
Frequency Display: Frequency LED's illuminates showing the
frequency on test.
Mode Display: Connection LED off.
Pass Battery indicator: LED Flash (if tested with poor batteries).
Audible Output: High - Low pulsed tone emitted three times.
Fail Battery indicator: LED Flash (if tested with poor batteries).
Audible Output: Low pitch tone emitted.
Mode Display: Induction or Connection LED illuminated to show failure
mode.
Frequency Display: Frequency LED illuminated to show frequency failure.
