114EZiSYSTEM, Functional Checks
A.3 Conductive Rod Functional Check
Checking the function The purpose of the following procedure is to verify the performance of the Conductive Rod.
To carry out this test the following are required:
A Transmitter for generating the signal in the Sonde and Line mode tests
The cable set for the Conductive Rod.
Plug the Transmitter’s cable set into the connection socket. Connect the red cable to the
positive (+) terminal on the conductive rod, connect the black cable to the negative (-)
terminal.
Switch the Transmitter on and adjust the power output on the Transmitter to minimum, the
audible output must be constant. Disconnect the black cable from the negative (-) terminal,
the audible output must be pulsed.
If any of these tests give no response or a significantly different response from normal, the
Conductive Rod should be returned for service.
