36EZiSYSTEM, How to Use the Locator
Data output Range Example value Description
DV 000 to 999 550 Model identifier
SN 000000 to 999999 123456 Serial number
SV 0.00 to 9.99 3.01 Software version
TM 00:00 to 23:59 08:30 Time: hh:mm
(default = 00:00; no RTC fitted)
DT 00/00/00 to 31/12/99 01/12/10 Date: dd/mm/yy
(default = 00/00/00; no RTC fitted)
CM 00 to 15 12 Number of months until next
calibration (00 to 15)
ST 0 or 1 0 Self test: 0 = Pass, 1 = Fail
BT 0 to 9 7 Battery level: 0 = Empty, 9 = Good
MD 0 to 6 3 Mode: 0 = Power, 1 = Radio,
2=8kHz, 3=33kHz, 4=Auto,
5 = 512 Hz, 6 = 640 Hz
SS 01 to 48 16 Signal strength: 01 to 48
UM M or I M Units of measurements:
M or I (Metres or Imperial)
DP 0.30 to 3.00 or --- 125 Depth value displayed depends on
value for UM.
