EZiSYSTEM, How to Use the Conductive Rod 51

• Ensure there are no services below the ground when using the Earth Pin. Use the
Locator in advance.
• At least half the Conductive Rod needs to be uncoiled when in use.
Using the Conductive
Rod in Sonde mode
1. Insert the rod into the pipe, duct, conduit or drain until the desired length is in place.
2. Plug the Transmitter’s cable set into the connection socket. Connect the red cable to the
positive (+) terminal on the conductive rod, connect the black cable to the negative (-)
terminal.
3. Switch the Transmitter on and select the required power output level and frequency
output. A good level of tracing signal is indicated when the power output LED & audible
tone changes from pulsed to continuous. The signal applies itself along the length of
the Conductive Rod.
4. Trace the length of the rod using the Locator set to the same frequency.

At least half the Conductive Rod needs to be uncoiled when in use.
