GEONAV 6 REGATTA
• Self-contained GPS plotter system
(Plotter + GPS receiver + Antenna)
• 12 -channel internal GPS, differential-ready
• Satellite acquisition time:
2 minutes (cold)
15 minutes first fix (with internal GPS)
• Possibility to use an external GPS via NMEA 0183
• Functions designed for sailing
• NMEA 0183 input for mast head transducer
• Integrated depth sounder via NMEA 0183 (optional)
• Built-in world map
• Autopilot
• Chart rotation (head-up display)
• Splash-proof
• Panel mounting
• Weight: 1 kg
Electrical characteristics
• Input voltage: 11VDC to 18 VDC with reverse polarity and overvolt-
age protection
• Power consumption: 0.5 W
• Operating temperature: 0° to +60° C, humidity 93%
• Storage temperature: -20°C to 70°C, humidity 93%
• 4-color LCD with high visibility under sunlight
• Adjustable backlight and contrast
• Backlight keypad
• Pixel resolution: 240 x 320
• 32-bit RISC processor
Memory characteristics
• 1 reversible route
• Up to 20 waypoints per route
• 1 track, up to 500 trackpoints
• Up to 99 markers
Interface characteristics
• Standard NMEA 0183 sentences
- from the position sensor:
GLL, VTG, GGA, RMC, GSV, ZDA, RMA, GSA
- from the mast head transducer:
VWR
- from the depth sounder:
DBT, DBS, DPT, DBK, MTW
- to the autopilot:
APA, APB, XTE, RMB, BWC, GLL, VTG
If received from the GPS, the following sentences are transmitted:
GGA, RMC, ZDA
Accessories
• Bracket for fixed installation
• Gasket and drilling template for panel mounting
• Power supply cable for connection to external GPS, mast head trans-
ducer, depth sounder and autopilot
• User’s manual
• Protection cap
• Carrying case
Characteristics
Regatta Regatta
