GeoVision GV-BX2400-0F User Manual

PTZ Camera
12
Starting and Stopping Autopan
To start an Auto Pan, click the Option button (No. 6, Figure 12-15), select
Auto and select a desired Auto Pan number. The PTZ Camera will first
return to the starting position of the selected Auto Pan and proceeds with
the selected Auto Pan movement.
To stop Auto Pan, click the
Option button (No. 6, Figure 12-15), select
Auto and select Autopan Stop. Alternatively click on a Pan / Tilt Control
button (No. 2, Figure 12-15) or the
Home button (No. 3, Figure 12-15).
Rebooting the Camera
When the system crushes and fails to respond to the PTZ control panel,
reboot the camera.
1 Open the VISCA OSD Configuration dialog box.
2 Click the
Motor Reset button to reboot.
3 Wait until the camera has panned and tilted its full range and
returned to the home point.
165

GeoVision GV-BX2400-0F Specifications

General

Image Sensor	1/3" progressive scan CMOS
Sensor Type	CMOS
Lens Type	Fixed
Minimum Illumination (B/W with IR on)	0 Lux
Gain Control	Auto
Video Compression	H.264, MJPEG
Frame Rate	30 fps at 1920 x 1080
Network Interface	10/100 Ethernet
Operating Humidity	10% to 90% (non-condensing)
Ingress Protection	IP66
Day/Night	Yes
WDR	Yes
Picture Elements	1920 x 1080
Resolutions	1920 x 1080, 1280 x 720, 640 x 480
Focal Length	4mm
Shutter Speed	1/5 ~ 1/8000 sec
White Balance	Auto, Manual
S/N Ratio	50 dB
Audio Compression	G.711
Audio Output	Yes
Protocols	TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, ICMP, UPnP, SNMP, SMTP, NTP
Connectors	RJ-45
Power Supply	12V DC
Power	12V DC
Operating Temperature	-20°C ~ 50°C (-4°F ~ 122°F)
Weight	350 g
Effective Pixels	2.0 MP
Lens	4.0 mm
