GeoVision GV-BX2400-0F User Manual

504
Operation (Focus / Zoom /
Iris)
Fixed
IR LED Quantity 8 IR LEDs
Max. IR Distance 15 m (50 ft)
Operation
Video Compression H.264, MJPEG
Video Stream Dual streams from H. 264 or MJPEG
Frame Rate 30 fps at 1280 x 1024
Image Setting
Brightness, Contrast, Saturation,
Sharpness, Gamma, White Balance,
Flicker-less, Image Orientation, Shutter
Speed, D/N Sensitivity, Backlight
Compensation, WDR, Defog
Audio Compression G.711, AAC (Optional)
Audio Support One-Way Audio
Note: The frame rate and performance may vary depending on the number of
connections and data bitrates (different scenes).
Video Resolution
4:3 1280 x 960, 640 x 480, 320 x 240
16:9 1280 x 720, 640 x 360, 448 x 252
Main
Stream
5:4 1280 x 1024, 640 x 512, 320 x 256
4:3 640 x 480, 320 x 240
16:9 640 x 360, 448 x 252
GV-EBX1100
Series
Sub
Stream
5:4 640 x 512, 320 x 256

GeoVision GV-BX2400-0F Specifications

General

Image Sensor	1/3" progressive scan CMOS
Sensor Type	CMOS
Lens Type	Fixed
Minimum Illumination (B/W with IR on)	0 Lux
Gain Control	Auto
Video Compression	H.264, MJPEG
Frame Rate	30 fps at 1920 x 1080
Network Interface	10/100 Ethernet
Operating Humidity	10% to 90% (non-condensing)
Ingress Protection	IP66
Day/Night	Yes
WDR	Yes
Picture Elements	1920 x 1080
Resolutions	1920 x 1080, 1280 x 720, 640 x 480
Focal Length	4mm
Shutter Speed	1/5 ~ 1/8000 sec
White Balance	Auto, Manual
S/N Ratio	50 dB
Audio Compression	G.711
Audio Output	Yes
Protocols	TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, ICMP, UPnP, SNMP, SMTP, NTP
Connectors	RJ-45
Power Supply	12V DC
Power	12V DC
Operating Temperature	-20°C ~ 50°C (-4°F ~ 122°F)
Weight	350 g
Effective Pixels	2.0 MP
Lens	4.0 mm
