Box Camera
2
2.5.2 Infrared Illuminators (Optional)
If you use an infrared (IR) illuminator with I/O function, follow the steps
below to install it.
1. Connect the infrared illuminator to the terminal block on the camera.
See 2.6 The I/O Terminal Block.
2. Access the Web interface of the camera.
3. Select Video and Motion, select Video Settings, select Streaming 1
and set the IR Check Function option to be Trigger by Input or
Trigger IR by D/N.
4. Click Apply.
For the Trigger by Input or Trigger IR by D/N function and D/N sensitivity
settings, see 21.1.1 Video Settings.
19
