GeoVision GV-VS14 Quick Start Guide

Getting Started
11
2
2.3 Overview
2.3.1 Main Window
By default, there are three areas on the main window.
No. Name Description
1 Camera Channels Displays the live views / recordings of added hosts.
2 Device Lists &
Layout
Contains the hosts added to the GV-Edge Recording Manager
and their I/O devices, and configures layout settings.
3 Toolbar Contains buttons to quickly access system settings, functions
and close image windows.
For more details, see 1.2 The Toolbar, 1.3 The Host List and 4.1 The Live View Window
respectively in GV-Edge Recording Manager User’s Manual.

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
